Description:
| Model | HK-260X Vario |
| Lathe | |
| Dsitance between centers | 750mm |
| Swing over bed | 260mm |
| Swing over cross slide | 150mm |
| Withd of bed | 145mm |
| Spindle taper | MT4 |
| Spindle through hole | 26mm |
| Spindle speed | 80-1600rpm, 12級(jí)(80/108/140/180/236/315/410/550/710/925/1225/1600) |
| Longitudinal feeds | 0.1-0.18mm |
| Imperial threads | 8-56 T.P.I. |
| Metric threads | 0.2-3.5mm |
| Top slide travel | 50mm |
| Cross slide travel | 140mm |
| Tailstock quill travel | 60mm |
| Taper of tailstock quill | MT2 |
| Motor power | 750W |
| Packing size (L*W*H) | 1500*760*600mm |
| N.W./G.W. | 170kg/195kg |
| Mill head | |
| Drilling capacity | 16mm |
| Face milling capacity | 50mm |
| End milling capacity | 16mm |
| Spindle taper | MT2 |
| Spindle stroke | 50mm |
| Spindle speed | 50-2250rpm |
| Head rotation | ±45° |
