Location:Home>Business>30-40W On-line Foot Dimmable LED Driver

30-40W On-line Foot Dimmable LED Driver

Product Model: SIAH...BF3

Brand: SINOBASE

MOQ: 300

Origin: CHINA

Email Enquiry

Features:

  • Constant current mode

  • Output SELV protection, short circiut, over current and over voltage protection

  • Extremely high precision current;

  • Dimming range: 3%-100%

  • High power factor

  • Dimming mode: stepless adjusted or single adjusted


Standards:

TUV EN60950-1            EN61347-2-13              EN55015                 EN55022(CISPR22)             EN61000-3-2

EN61000-3-3                EN61000-4-2                ENV50204               EN55024



Specification:

ModelsInput Voltage (V)P.F.Output Voltage (V)Output Current(mA)Output Power (W)

Dimension

L*W*H(mm)

SIAH62065BF3220-240Vac
0.95
46-62V650mA30-40W

125.5*76.5*33.2

SIAH57070BF342-57V700mA
.........
SIAH27A15BF320-27V1500mA

P.S.: The current step is 50mA, contact us for the specs out of above tables.





Application:
